Constructive CAD CE • Modeling in AutoCAD

  BMEEPAG0249 • elective course • 2018-19-1

LAYAL CHAMAS


Simple Model

Designing interior spaces of "4 by 4" house by architect Tadao Ando using simple furniture elements.

Pictures

[PICTURE]  [PICTURE]  [PICTURE]  [PICTURE]  [PICTURE]  [PICTURE]

Complex Model

Located in the eastern suburban area of Rome, the Church of 2000 “Dives in Misericordia” by architect Richard Meier is conceived as a composition of basic elements, clearly referred to the purity of the cube and the sphere, and the in-between spaces and connections.

Pictures

[PICTURE]  [PICTURE]  [PICTURE] [PICTURE]
